MTD0060AZOF
• Type: OLED
• Size: 0.6 inch
• Resolution: 64 x 64
• Brightness: 200
• Interface: SPI
• Driver IC: SSD1357Z
• Pin Count: 20
• View Cone: All Angles
• Operating Temp: -40 ~ 70

• Type: OLED
• Size: 3.12 inch
• Resolution: 264 x 64
• Brightness: 80
• Interface: 8-bit 8080,8-bit 6800, SPI
• Driver IC: SSD1322
• Pin Count: 30
• View Cone: All Angles
• Operating Temp: -30 ~ 85

Features of Microtips Technology’s Round Display:

• High-Brightness and High-Readability
• Custom Cover Glass Available
• Capacitive Touchscreen Available
• Cost Effective
• Long-term Availability

Solutions:
• Smart Knob Control
• Digital Meter
• Smart Gauge
• Smartwatch
• Medical and Automotive Devices, etc.

AWY-4001280T78N01
• Type: TFT, Bar-Type
• Size: 7.84″
• Resolution: 400 x 1280
• Interface: MIPI
• Brightness: 900
• Touch Panel: Optional
• Op Temp: -20 ~ 70 C
• View Angle: 80/80/80/80

Solutions:

• Digital Signage
• Transportation Systems
• Healthcare
• Automotive Devices, etc.
Try a Microtips’ Bar-Type Display, and see how we can make your product more usable and better looking!

AWL-320960T46N01
• Type: TFT, Bar-Type
• Size: 3.99 inch
• Resolution: 400 x 960
• Brightness: 350
• Interface: SPI + RGB
• Driver IC: ST7701S
• Pin Count: 40
• View Cone: 85/85/85/85
• Fluid: IPS

AWL-320960T46N01
• Type: TFT, Bar-Type
• Size: 4.6 inch
• Resolution: 320 x 960
• Brightness: 300
• Interface: SPI + RGB
• Driver IC: ST7701S
• Pin Count: 40
• View Cone: 80/80/80/80
• Fluid: IPS

AWL-240960T37N01
• Type: TFT
• Size: 3.71 inch
• Resolution: 240 x 960
• Brightness: 350
• Interface: SPI + RGB
• Driver IC: ST7701S
• Pin Count: 40
• View Cone: 85/85/85/85
• Fluid: IPS

MTD0140AZP03SF-1
• Type: TFT
• Size: 1.4 inch
• Resolution: 240 x 240
• Brightness: 580
• Interface: SPI
• Driver IC: ST7789V2
• Pin Count: 24
• View Cone: 80/80/80/80
• Fluid: IPS

New Round Display
AWD-10801080T50N01
Key Features
• Type: TFT
• Size: 5.0 inch
• Resolution: 1080 x 1080
• Brightness: 400
• Interface: MIPI
• Operating Temp: -20 ~ 60
• Fluid: IPS
• Polarizer: Transmissive
• View Cone: 80/80/80/80
